Transformer Inspection Series

Qilida Solutions

Next-Generation Transformer Testing Instrument

Revolutionary precision meets unmatched reliability. The qilida delivers comprehensive transformer testing with industry-leading accuracy up to 0.05%, supporting IEC 61869 and IEEE C57.13 standards for critical power infrastructure testing.

Enquiry Today

Advanced Testing Capabilities

Ultra-High Precision

Industry-leading ±0.05% accuracy for ratio measurements with automatic temperature compensation and drift correction. Supports testing from 1:1 to 30,000:1 ratios with consistent precision.

Multi-Standard Compliance

Native support for IEC 60044-1/2, IEC 61869-2/3/5, IEEE C57.13, and ANSI standards. Automatic test limit configuration and pass/fail criteria for global compliance requirements.

Rapid Testing Suite

Complete transformer characterization in under 2 minutes. Simultaneous measurement of ratio error, phase displacement, excitation current, and burden with single-connection setup.

Advanced Diagnostics

Integrated partial discharge detection, insulation resistance testing, frequency response analysis, and thermal monitoring for comprehensive transformer health assessment.

Smart Connectivity

Wi-Fi, Bluetooth, and Ethernet connectivity with cloud data synchronization. Mobile app control and real-time monitoring capabilities for remote testing operations.

AI-Powered Analysis

Machine learning algorithms for predictive maintenance recommendations, trend analysis, and automatic anomaly detection based on historical testing data patterns.

Solving Critical Testing Challenges

Problem Predicament

Traditional testing equipment often lacks the precision required for modern high-accuracy instrument transformers (Class 0.1 and 0.15), leading to incorrect assessments and potential billing inaccuracies.

Testing to multiple international standards (IEC 60044, IEC 61869, IEEE C57.13, ANSI) requires different equipment setups and procedures, increasing complexity and testing time.

Manual burden calculations, ratio adjustments, and data recording slow down testing procedures and increase the risk of human error in critical safety assessments.

Basic ratio testing misses critical insulation degradation, partial discharge, and mechanical issues that could lead to catastrophic transformer failures.

Solutions

Industry-leading ±0.05% accuracy with automatic temperature compensation and advanced digital processing eliminates measurement uncertainties.

Unified platform supporting all major international standards with automated test sequences and instant compliance reporting.

Fully automated testing with intelligent burden compensation, one-button operation, and integrated data management reduces testing time by 70%.

Comprehensive diagnostic suite including insulation resistance, partial discharge detection, frequency response analysis, and predictive maintenance algorithms.

Applications of Transformer Testing Instrument

Explore the key applications of transformer testing instruments, essential for ensuring reliability, efficiency, and safety in electrical systems.

Power Generation

Testing instrument transformers in power plants, renewable energy facilities, and distributed generation systems.

Transmission & Distribution

Comprehensive testing of substation CTs and VTs for grid reliability and protection system verification.

Industrial Facilities

Manufacturing plant electrical system testing, process industry monitoring, and energy management applications.

Railway Systems

Testing traction transformers and railway electrification systems for safe and reliable rail transport.

Laboratory Testing

Precision calibration and testing in electrical standards laboratories and certification facilities.

Commercial Buildings

Testing electrical systems in hospitals, data centers, and critical infrastructure facilities.

What Our Clients Say

The QILIDA has revolutionized our testing procedures. We've reduced testing time by 70% while significantly improving accuracy. The automated features and comprehensive diagnostics have eliminated many of our previous workflow bottlenecks.

Emily Johnson

Senior Electrical Engineer, PowerGrid Solutions

Outstanding precision and reliability. We've been using it for six months across multiple substations, and the consistency is remarkable. The predictive maintenance features have helped us identify potential issues before they become critical failures.

David Smith

Testing Supervisor, Metro Electric Utility

The multi-standard compliance feature is a game-changer for our international projects. One device handles all our testing requirements across different regions. The data management and reporting capabilities are exceptional.

Sophia Miller

QA Manager, Global Transformer Manufacturing

Why Choose QilidaOver 15 years of transformer testing expertise with 10,000+ successful installations worldwide across 50+ countries.

Industry-Leading Support: 24/7 support, training, and local service centers for quick response and maintenance.

Future-Proof Technology: Expandable functionality, firmware updates, and compatibility with emerging testing standards.

ROI Optimization: Cut testing time by 70%, reduce downtime, and enable predictive maintenance.

Comprehensive Solution: Integrated software, cloud data, and mobile apps for efficient workflows.

Quality Assurance: ISO 9001 certified, NIST traceable calibration, and strict quality control for reliability.
