Qld-9102 Partial Discharge Analyzer

The QL-DCGF DC High Voltage Generator is designed for use in scientific and industrial environments where stable and accurate high-voltage is required. The key features include adjustable voltage control, solid construct, embedded safety features, and compact design. All but allowing easy integration, it is particularly noted for insulation reflection and in high-energy physics applications, to guarantee performance and user safety.

Key Features and Specifications

Detection Capabilities:

Detects partial discharge, corona discharge, gas, and vacuum leaks.
Frequency range: 2 kHz to 100 kHz.
Detection range: 0.5 to >120 meters (1.6 to >393 feet).

Ease of Use:

Intuitive interface with minimal training required.
7-inch LCD touchscreen for easy navigation and visibility.
One-button capture for images and videos.

Safety and Efficiency:

Enables detection from a safe distance (up to 120 meters).
Reduces downtime and increases uptime by identifying issues early.
Prevents catastrophic failures like blackouts, fires, and arc flashes.

Data and Reporting:

Internal memory for 999 pictures and 20 videos.
Supports .JPG, .PNG, and .MP4 formats.
Includes PDQ Mode™ for partial discharge analysis and reporting.

Durability:

Rugged design for industrial environments.
IP40 protection rating.
Operating temperature: 0°C to 40°C (32°F to 104°F).

Battery Life:

Includes two rechargeable lithium-ion batteries.
Each battery lasts up to 6 hours.

Data Presentation

Feature	Details
Frequency Range	2 kHz to 100 kHz
Detection Range	0.5 to >120 meters
Display	7-inch LCD touchscreen, 1280 x 800 resolution
Battery Life	6 hours per battery (includes 2 batteries)
Weight	2.15 kg (4.74 lbs)
Memory Capacity	999 pictures, 20 videos
Safety Distance	Up to 120 meters
Applications	Insulators, transformers, powerlines, switch gears, and more
Cost Savings	Prevents downtime costing $8,851 per minute
Durability	Rugged design, IP40 protection
